Shrink Wrapping Machine


420mmLong Bar Soap
SS Covers
Suitable for Soap Bar
Wrapping Type- Flow Wrapper
Conveyor -5 Feet Long
Center Sealing Pillow Shape Wrapping
Max Pouch Size: 300mmLx200mmWx100mmH
Digital Control Panel
Power:380V 3 Phase/50Hz/2 KW
Machine Dimension: 5 Feet L x4 Feet W x 5 Feet H
Weight- 500Kg Approx.



Suitable for

Shrink Wrap Products



Tunnel Sizes available

8”x8”/ 12”x12”/14x16”/18x20”




4KW to16KW

Power Source

220V 50Hz


220V 50Hz

Power Supply

2KW (as per model selection)

Compressed Air




Conveyor Length

1200mm ( as per model selection)


Shrink wrapping machine is majorly used to wrap objects with film
Shrink tunnels are of different sizes to apply on various product sizes
Shrink wrapping machine is consited of shrink tunnel of 8 to 36 “ tunnel size in width.
Shrink tunnels are widely used to wrap objects with shrink sleeves.
Shrink warpping machine can be used as sleeve labelling machine to apply sleeves on packaged drinking water, glass bottles.
Shrink sleeve labelling is major use of shrink tunnel to get better labelling machine accuracy.
Different types of shink tunnels can be designs to apply sleeves on bottles with various shrink wrapping machines.
Shrink packaging is a method of applying skin tight labelling on bottles.
Shrink wrapping equipments are widely used in food packaging & pharmaceutical packaging.
PVC shink labelling machine and Pvc shrink sleeve applying is similar machine applications.
Shink tunnel is suitable for PVC shink labelling and Pvc shrink sleeve applying .

Technical feature :
* Two large power blowing blows ensure enough circulating air;
* Conveying speed is controlled by the imported frequency inverter;
* A baffle is fixed both on the entrance and exit of the tunnel, prevent the heat inside the tunnel going out;
* The imported insulation curtain lowers the waste of the heat inside tunnel;
** The tunnel's height can be adjusted by the ground bolt to meet different height of the production line;
* The S/S heaters increase the temperature fast and they can be used for 5-10 years;
* The worm gear reducer and large power motor ensure the stable conveying;
* There are four wheels on the bottom of the machine, so can move machine freely;
* Specially designed wind path makes the products shrinked evenly;
* Adopts adjustable wind mesh panels inside the tunnel, the blowing wind is adjustable;
* Adopts large power cooling blower, makes products cooled and formed in a short time.
Max. Machine dimension L×W×H(mm)  2800×970×1400
Max packing size L×W×H(mm)  1000×400×250
Worktable height  750mm
Packing speed (pcs/h)  3000-5000
Power (kw)  21
Machine weight 350kg
Power supply 3φ220V/380V 50/60Hz

Suiatble to wrap any object,box,bottles with shrink film
Compac design with Air Cooled sytem
SS mesh passing conveyor
Available in 5x8", 6x8", 12x12" & 16x16" tunnel sizes
Adjustable temp & conveyor drive
Speed: 10 packs per Minute


Control Panel
Control Panel


Shrink Tunnel
Shrink Tunnel

Shrinked Packs
Shrinked Packs

Shrink Wrapping Machine
