Cup Filling Machine



Product Video

Product Description

TECHNICAL DETAILS

MODEL NO. RCFSM (CUSTOMIZED)

Suitable for

Yogurt, Dahi, Juice, Liquid Cups

Cup Dia

40-95mm

Filling Range

50ml-500ml

Filler Type

Gravimetric

Product Hopper

50Lit.

Sealing Type

Heat Seal Foil Sealer

Indexer

Geneva

Motor Drive

1HP

Heater

2KW

Turret

8 Station

Cup Feeding

Manual

Foil Feeding

Automatic

Power Source

220V 50Hz

Power Supply

3KW

Contact Parts

Stainless Steel 316 Grade

Covers

Stainless Steel

Feature

No Cup-No Foil

Machine Weight

800Kg

Machine Dimension (Wooden Case)

1200mmLx1200mmWx 1500mmH

Production Capacity

16 Cups Per Minute (also available in 30,60cpm)

Cup filling machine is Rotary Cup Filling Machine for Icecream cup filling, Yogurt cup filling, Honey, Curd, Buttermilk filling , Shrikhand in PVC, Plastic cups.

Cup filling machine is suitable for Filling & Lid Sealing of cups.

Suitable to fill 5gm-1Kg.

Rotary Machine with 8-Stational operation.

Automatic cup pickup from stacker hopper

Automatic Single head timer based pump filler unit.

Single Head foil pick-up & Sealing unit with automatic ejection system.

1Hp Motor driven.

SS304/SS316 Contact Parts.

Power: 415V 3-Phase-50HZ, Heater: 600W

Compact Model

+1%filling accuracy

TECHNICAL DATA :

Speed 15-30 Cups/Minute

Compressed Air 8 - 10 Nm³/h at 7 bar.

Current 6,5 kW - 230/400 V

Frequency 50 Hz

System 4-line rotary

Weight 500 kg
